Resmed AirCurve 10 ST BiPAP Machine

Resmed AirCurve 10 ST BiPAP Machine is a bilevel device with backup rate that provides exceptional synchrony, reducing the work of breathing so you remain comfortable and well-ventilated. It’s an ideal choice for reliable, cost-effective noninvasive ventilation when alarms are not required.

3 Years Warranty if you buy from authorized dealers (Register your device at https://www.resmed.co.in/rewards)

Resmed AirCurve 10 ST BiPAP Machine Features:

• TiControl™ Ti Max enables you to set a maximum inspiratory time to reduce the risk of intrinsic PEEP and missed effort, while Ti Min ensures adequate time for gas exchange without having to increase the pressure setting.
• Trigger and cycle sensitivities Adjustable trigger sensitivity supports to a weak inspiratory effort.
• Vsync continuous leak management enables reliable delivery of therapy pressure while maintaining synchrony. The device can quickly compensate for the leak and maintain breathing synchrony.
• HumidAir Humidifier to prevent dry mouth and throat.
• VPAP ST The device provides inspiratory positive airway pressure and also has a backup rate to make sure that you get enough breaths per minute, even when you do not breathe spontaneously.
• Pressure Range of 3-25 cm H20 The VPAP ST is intended for those with central sleep apnea, who generally need more air pressure than those with obstructive sleep apnea.
• SD Card Ready This VPAP device has the capacity to store up to 365 days of summary and compliance data, 30 sessions of detailed data and 7 sessions of high resolution flow data.
  Resmed AirCurve 10 ST BiPAP Machine Specifications:

  Feature	Specification
  Manufacturer	ResMed
  Model	AirCurve 10 ST BiPAP
  Therapy Mode	Bi-Level Positive Airway Pressure (BiPAP)
  Inspiratory Pressure Range (IPAP)	4 to 25 cm H2O
  Expiratory Pressure Range (EPAP)	4 to 25 cm H2O
  Pressure Support Range	0 to 25 cm H2O
  Ramp Time	0 to 45 minutes (5-minute increments)
  Ramp Starting Pressure	4 to CPAP Pressure
  Climate Control Compatibility	Optional ClimateLine™ heated tubing
  Pressure Relief	EPR (Expiratory Pressure Relief)
  Data Management	Built-in cellular technology (AirView™)
  Data Display	LCD Screen
  Power Supply	90W Power Supply (Auto-Sensing 100-240V)
  Sound Level	26.6 dBA (at 10 cm H2O, average)
  Dimensions (Machine Only)	4.57" H x 10.04" W x 5.91" D (11.6 cm x 25.5 cm x 15 cm)
  Weight (Machine Only)	2.75 lbs (1250 g)
  Warranty	3 years
  Operating Altitude	Sea level to 8,500 feet (2,591 meters)
  Operating Temperature Range	+41°F to +95°F (+5°C to +35°C)
  Operating Humidity Range	10% to 95% relative humidity, non-condensing
  Storage and Transport Temperature Range	-4°F to +140°F (-20°C to +60°C)
  Storage and Transport Humidity Range	5% to 95% relative humidity, non-condensing
  Maximum Recommended Pressure Support	15 cm H2O
  Therapy Compliance Data	SD Card
  Therapy Mode Alerts	Visual and Audible

  Resmed AirCurve 10 ST BIPAP with Humidifier Box Contents:

  • • AirCurve 10 ST Device
    • HumidAir Heated Humidifier
    • SlimLine Tubing
    • Power Supply Unit
    • Travel Bag
    • Air Filter (Pre-installed)
    • SD Card ready (the card is already inserted)
    • User Manual

  (FAQs) ResMed AirCurve 10 ST BiPAP machine:



  1. What is the Resmed AirCurve 10 ST BiPAP Machine used for?

  – The AirCurve 10 ST BiPAP machine is used to provide Bi-Level Positive Airway Pressure (BiPAP) therapy for individuals with sleep apnea or other respiratory conditions. It delivers two different pressures, one for inhalation (IPAP) and one for exhalation (EPAP), to help keep the airway open during sleep.

  2. How does the Resmed AirCurve 10 ST BiPAP Machine differ from other BiPAP machines?

  – The AirCurve 10 ST BiPAP machine is equipped with intelligent features such as Easy-Breathe technology, which mimics natural breathing patterns to enhance comfort during therapy. It also offers advanced data management capabilities through built-in cellular technology for remote monitoring and adjustments.

  3. What is Pressure Support and how does it work on the Resmed AirCurve 10 ST BiPAP Machine?

  – Pressure Support is the difference between the Inspiratory Positive Airway Pressure (IPAP) and Expiratory Positive Airway Pressure (EPAP). It helps to provide additional support during inhalation, making it easier to breathe against the therapy pressure. The AirCurve 10 ST allows adjustment of the Pressure Support within a specified range to suit individual needs.

  4. Can I use the AirCurve 10 ST BiPAP machine with a heated humidifier?

  – Yes, the AirCurve 10 ST is compatible with ResMed’s ClimateLine™ heated tubing and humidifier systems. Adding a heated humidifier can help reduce dryness and irritation often associated with CPAP and BiPAP therapy, enhancing overall comfort.

  5. How often should I replace the filters and other components of the AirCurve 10 ST?

  – It is recommended to replace the disposable filters every 1 to 3 months, depending on usage and environmental factors. Additionally, other components such as the mask, tubing, and water chamber should be cleaned and replaced according to the manufacturer’s instructions to maintain optimal performance and hygiene.

  6. Is the AirCurve 10 ST BiPAP machine portable for travel?

  – While the AirCurve 10 ST BiPAP machine is designed primarily for home use, it is relatively compact and lightweight, making it suitable for travel. Additionally, ResMed offers travel-friendly accessories and carrying cases for added convenience on the go.

  7. How can I access therapy data from the AirCurve 10 ST BiPAP machine?

  – The AirCurve 10 ST BiPAP machine features built-in cellular technology, allowing healthcare providers to remotely access therapy data for monitoring and adjustment purposes. Additionally, therapy data can be stored on an SD card for personal tracking and analysis.

  8. What should I do if I experience any issues or discomfort while using the AirCurve 10 ST BiPAP machine?

  – If you encounter any problems or discomfort during therapy, it is essential to consult with your provider or ResMed representative. They can offer guidance on troubleshooting, adjustment settings, and potential solutions to improve your therapy experience.
